Waterproof PDLC RRU Outdoor Fiber Optic Patch Cables 7.0mm Inside Armored
FOCC this kind of PDLC Waterproof fiber optic patch cables have standard size for Duplex LC Connectors, and the outer housing with metal protective device. The connecting is safe and reliable. Also have the functions of waterproof, dustpoof. PDLC fiber patch cord is widely used in FTTA, Base station, and the outdoor waterpoof condition.
Applications:
Widely used in FTTA & FTTH;
Used for 3G 4G base station;
BBU, RRU, RRH, LTE.
Features:
Standard Duplex LC connector, well connected with standard LC adaptor;
Wall seal design,easy operation, strong and durable;
Broad temperature range and wide range of indoor and outdoor cable;
Easy Operation, reliable and cost-effective Installation;
IP67 protection, salt-mist proof, humidity proof, dust proof;
Light weight,waterproof, dustproof, moistureproof , Metal hard housing.
PDLC Outdoor Armored Fiber Assembly Specifications:
| Item | Data |
| Insertion Loss | ≤0.3dB |
| Mechanical life | 500cycles |
| Working temperature | -40 ~ +70 |
| Storage temperature | -40 ~ +70 |
| Operating temperature | -40 ~ +70 |
| Protection Level | IP67 |
| Tensile Data | Tensile between junction and fiber cable≥180N |
| Out shell inflaming retarding | UL94 V-0 |
| Out shell Uvioresistant | UL 746C |
| Authentication | Meet with RoHS |
GYFJH 7.0mm fiber cable Specification:
| Item | Data |
| Fiber | Single mode G.657A1 or G.657A2 |
| Fiber diameter | 7.0mm |
| Material & Color for Jacket | LSZH Black |
| Tension Member | Aramid Fiber |
| Max. Attenuation | ≤ 0.4dB/km at 1310nm
≤0.3dB/km at 1550nm |
| Tensile Resistance(short term) | 500N(no breakage) |
| Crush Resistance(short term/long term) | 1000N/100mm |
| inflaming Retarding | IEC 60332-3 |
| Temperature | -40~+70 |
| Uvioresistant | PASS |
| Authentication | Meet with RoHS &UL |
Competitive Advantage:
FOCC strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, products exported to Europe and the United States and Southeast Asian countries.
